Johnson Controls FMS-2000C Installation Guide

FMS-2000C
LIT-12013508
47
Object instance Internal oat values Read or write
ADF-59 AI-2 deadband setting Read or write
ADF-60 AI-3 deadband setting Read or write
ADF-61 AI-4 deadband setting Read or write
ADF-62 TI-1 deadband setting Read or write
Object instance Internal integer values Read or write
ADI-1 AI-1 isolation mode: 1 = positive, 2 = negative, 3 = neutral Read or write
ADI-2 AI-1 alarm status: 1 = normal, 2 = warning, 3 = alarm Read only
ADI-7 AI-2 isolation mode: 1 = positive, 2 = negative, 3 = neutral Read or write
ADI-8 AI-2 alarm status: 1 = normal, 2 = warning, 3 = alarm Read only
ADI-9 AI-3 alarm status: 1 = normal, 2 = warning, 3 = alarm Read only
ADI-10 AI-4 alarm status: 1 = normal, 2 = warning, 3 = alarm Read only
ADI-11 TI-1 alarm status: 1 = normal, 2 = warning, 3 = alarm Read only
ADI-12 TI-2 alarm status: 1 = normal, 2 = warning, 3 = alarm Read only
Technical specications
Table 39: Internal integer values for integration in a BMS
Intended use
Indoor use
Overvoltage category
II
Altitude
Up to 2000 m
Pressure range
± 0.2500 in. W.C.
Alarm range
± 0.2500 in. W.C.
Display range
± 0.2500 in. W.C.
Accuracy
± 0.5% full scale
Air flow sensor type
Digital differential pressure features no offset, zero drift and is hysteresis free
Flow control resolution
± 0.0010 in. W.C.
Displayed pressure resolution
± 0.0001 in. W.C.
Control capability
Up to 4 independent spaces
I/O Resources
4 universal inputs (0 mA to 20 mA, 4 mA to 20 mA, 0 VDC to 5 VDC, 0 VDC to 10 VDC)
2 thermistor inputs (NTC Type 2 or 3, 10K at 77° F)
4 digital inputs (active-high or active-low 0 VDC to 5 VDC or 0 VDC to 24 VDC)
4 universal outputs (0 mA to 20 mA, 4 mA to 20 mA, 0 VDC to 5 VDC, 0 VDC to 10 VDC)
4 relay outputs (NO or NC contacts 1A at 24 VDC)
Operating temperature
32°F to 125°F (0°C to 52°C)
Operating humidity
10% to 95% relative humidity, non-condensing
Mounting
Thin mount for shallow wall cavities, surface mount for mounting to standard single-gang wall box
Alarm indication
360° Safety Halo color coded visual, audible alarm
Alarm silence
Touchscreen, auto-reset
Password protection
Up to 50 user passwords with 2 access levels (administrator and restricted)
Communications protocol
BACnet MS/TP (to BAS) 76.8k, 38.4k, 19.2k, 9600 baud, Metasys N2 open
