FMS-2000C
LIT-12013508
48
Power requirement
24 VAC (nominal, 20 VAC minimum/28 VAC maximum), 50/60 Hz 30 VA power supply, Class 2,
Limited Energy, or LPS
Power consumption 30 VA maximum
Optional input power supply
Universal 120 VAC/240 VAC-to-24 VAC, 30 VA step-down isolation transformer
24 VAC-to-24 VAC, 30 VA isolation transformer
Display resolution
720 pixels x 1280 pixels
Pluggable screw terminal blocks
18 AWG to 22 AWG (1.0 mm to 0.6 mm diameter)
Display dimensions
(height x width x depth)
5.3 in. x 3.5 in. x 1.17 in. (134.62 mm x 88.9 mm x 29.72 mm)
Mounted depth
0.58 in. (14.73 mm)
Controller dimensions
(height x width x depth)
6.56 in. x 5.5 in. x 1.88 in. (166.62 mm x 139.7 mm x 47.75 mm)
Power supply enclosure dimensions
(height x width x depth)
5 in. x 4.7 in. 2.3 in. (127 mm x 119.38 mm x 58.42 mm)
Compliance United States
UL Listed to UL 61010-1; FCC 47CFR Part 15; BTL Listed
Canada
cUL Listed to CAN/CSA C22.2 NO. 61010-1; ICES-003
Europe
CE (EMC Directive) to EN 61326-1
Australia and New
Zealand
RCM Mark (Australian Radiocommunications Act) to EN 61326-1
Feature Code letter or number and description Product code number example:
LB-FMS2C-BT21
Product name LB LB
Unit FMS = Flow Monitor Station (FMS) FMS
Series 2 = 2000
C = Controller
2C
Network B = BACnet/N2 (Controller included) B
Mounting style T = Thin
S = Surface
T
Remote sensor
1
0 = No remote sensors
1 = One remote sensor
2 = Two remote sensors
3 = Three remote sensors
4 = Four remote sensors
2
ISO power 0 = 24 V power supply by others
1 = 120 V to 240 V/24 V
2 = 24 V/24 V
1
1
If you plan to use third party sensors, select 0.
Product code matrix
Table 40: FMS-2000C Critical Environment Controller ordering guide
