FMS-2000C

LIT-12013508

BACnet objects

See Table 28 to Table 33 for a list of points available for integration in a building management system (BMS). They contain the objects

for open BACnet integration.

Object Analog inputs Read or write

AI-1 Analog input 1, default: isolation pressure Read only

AI-2 Analog input 2 Read only

AI-3 Analog input 3 Read only

AI-4 Analog input 4 Read only

AI-5 Thermistor input 1 Read only

AI-6 Thermistor input 2 Read only

Object Analog outputs Read or write

AO-1 Analog output 1, default: damper position Read only

AO-2 Analog output 2, default: anteroom damper control Read only

AO-3 Analog output 3, spare control output Read only

AO-4 Analog output 4, spare control output Read only

Object Binary inputs Read or write

BI-1 Digital input 1, default: door switch Read only

BI-2 Digital input 2, default: anteroom door switch Read only

BI-3 Digital input 3, spare digital input Read only

BI-4 Digital input 4, spare digital input Read only

Object Binary outputs Read or write

BO-1 Relay output 1, default: primary alarm relay output Read only

BO-2 Relay output 2, default: spare relay output Read only

BO-3 Relay output 3, spare relay output Read only

BO-4 Relay output 4, spare relay output Read only

Table 28: Analog inputs for integration in a BMS

Object Analog values Read or write

AV-1 AI-1 setpoint for room pressure Read or write

AV-2 AI-2 setpoint Read or write

AV-3 AI-3 setpoint Read or write

AV-4 AI-4 setpoint Read or write

AV-5 TI-1 setpoint Read or write

AV-6 TI-2 setpoint Read or write

AV-7 Air change rate based on flow input at AI-1 Read only

AV-8 Air change rate based on flow input at AI-2 Read only

AV-9 Air change rate based on flow input at AI-3 Read only

AV-10 Air change rate based on flow input at AI-4 Read only

AV-11 Alarm relay 1 high setpoint Read or write

Table 29: Analog outputs for integration in a BMS

Table 30: Binary inputs for integration in a BMS

Table 31: Binary outputs for integration in a BMS

Table 32: Analog values for integration in a BMS
