FMS-2000C
LIT-12013508
39
Note: For optimum network communications, connect the reference signal REF to the NETWK REF terminals at the backplane.
Wiring communications to Metasys N2 open
DIP switch ON or OFF Protocol
S3 position 7 ON Metasys N2 protocol selected
S3 position 8 OFF
Figure 33: Metasys N2 open wiring diagram
Table 19: Controller conguration DIP switch settings
Controller
Controller
Controller
Supervisory Device
