FMS-2000C
LIT-12013508
14
Monitored spaceReference space
Number Description
1 Gasket
2 Stainless steel flow tube mounting plate
3 Wall section in cut away view
4 Flow tube
5 Stainless steel mounting plate
6 Gasket
7 Louvered cover plate
8 Terminal block
9 Thin silicone caulking
Figure 8: Standard remote sensor 9-pin side view
Table 3: Remote sensor installation components
