Johnson Controls (H,Y,C)IDM012B21S User Manual

INDOOR UNITS
3-26
TC-15001-rev.3
3.1.4.8 Electrical Data
VOL: Rated Unit Power Supply Voltage (V)
PH: Phase
HZ: Frequency (Hz)
MCA: Minimum Circuit Ampacity (A)
MFA: Maximum Fuse Ampacity (A)
237 5DWHG0RWRU2XWSXWN:
FLA: Full Load Ampacity (A)
Model
Unit Main Power Applicable Voltage Power Supply
Indoor
Fan Motor
Unit
VOL PH HZ Maximum Minimum MCA MFA OPT FLA
(H,Y)IDM006B21S
208/230 1 60 253 188
0.60 5 0.15 0.67
(H,Y)IDM008B21S 0.60 5 0.15 0.67
(H,Y)IDM012B21S 0.60 5 0.15 0.67
(H,Y)IDM015B21S 0.60 5 0.15 1.03
(H,Y)IDM018B21S 0.60 5 0.15 1.03
(H,Y)IDM024B21S 1.01 5 0.25 1.17
(H,Y)IDM030B21S 1.01 5 0.25 1.38
(H,Y)IDM036B21S 1.01 5 0.25 1.98
(H,Y)IDM048B21S 1.01 5 0.25 2.19
NOTE:
3RZHUVXSSO\YROWDJHVKRXOGEHVDWLV¿HGZLWKWKHIROORZLQJ
Supply Voltage: Rated Voltage within ±10%
Starting Voltage: Rated Voltage within -15%
Operating Voltage: Rated Voltage within ±10%
