5. Optional Parts
5.1 Line Up
Item
No.
Type
Adopting
Model Name
Item
No.
Optional Parts
Optional Parts
Model Name
Adapting
5.2 Outdoor Unit
(H,Y)VAHR072
~120B(3)(4)1S
5.2.1 Drain Adapter DBS-TP10A
5.2.2
Protection
Net
Protection Net (Rear) PN-TP10BA For 072
Protection Net (Rear) PN-TP10BB For 096 and 120
Protection Net (Right) PN-TP10R For 072 to 120
Protection Net (Left) PN-TP10L For 072 to 120
5.2.3
Snow
Protection
Hood
Snow Protection Hood (Upper) ASG-TP20FAS1 For 072
Snow Protection Hood (Upper) ASG-TP20FBS1 For 096 and 120
Snow Protection Hood (Rear) ASG-TP20BAS1 For 072
Snow Protection Hood (Rear) ASG-TP20BBS1 For 096 and 120
Snow Protection Hood (Right) ASG-TP20RS2
Snow Protection Hood (Left) ASG-TP20LS2
5.3 Ducted
Ducted
High
Static
(H,Y)IDH018B
~048B21S
5.3.1 Air Filter
KW-PP8Q For 018
KW-PP3Q For 024 to 030
KW-PP4Q For 036 to 048
Ducted
Medium
Static
(H,Y)IDM006
~048B21S
KW-PP7Q For 006 to 012
KW-PP8Q For 015 to 018
KW-PP9Q For 024 to 030
KW-PP10Q For 036 to 048
Ducted
Slim
(H,Y)IDS006
~018B21S
KW-PP5Q For 006 to 012
KW-PP6Q For 015 to 018
5.4 4-Way Cassette
(H,Y)IC4012
~036B21S
5.4.1 Anti-bacterial Air Filter
F-71M-K2 For 012 to 018
F-160M-K2 For 024 to 036
5.4.2 Filter Box B-160H3
5.4.3 Air Outlet Shutter Plate PI-160LS2
5.4.4 Fresh Air Intake Kit OACI-160K3
5.4.5 T-Tube Connecting Kit TKCI-160K
5.4.6 Duct Adapter PD-75A
5.5 1-Way Cassette
(H,Y)IC1006
~015B21S
5.5.1 Anti-bacterial Air Filter F-56MS-PK2
5.5.2 Motion Sensor Kit SOR-NES
5.5.3 Duct Adapter PD-100
5.5.4 Grille for Front Discharge DG-56SW1
5.5.5 Air Outlet Shutter Plate PIS-56LS
5.6 Wall Mounted
TIWM006
~024B21S
5.6.1 Strainer Kit
MSF-NP63A For 006 to 015
MSF-NP112A For 018 and 024
5.7 Piping Kit —
5.7.1
Piping Connection Kit
for Heat Pump System (2-Pipes Connection)
MC-NP21A1 For 2 Module
MC-NP30A1 For 3 Module
MC-NP40A1 For 4 Module
5.7.2
Piping Connection Kit
for Heat Recovery System (3-Pipes Connection)
MC-NP21X1 For 2 Module
MC-NP30X1 For 3 Module
MC-NP40X1 For 4 Module
5.7.3
Multi-Kit (Line Branch)
for Heat Pump System (2-Pipes Connection)
MW-NP282A2
MW-NP452A2
MW-NP692A2
MW-NP902A2
5.7.4
Multi-Kit (Line Branch)
for Heat Recovery System (3-Pipes Connection)
MW-NP142X2
MW-NP282X2
MW-NP452X2
MW-NP562X2
MW-NP692X2
MW-NP902X2
5.7.5
Multi-Kit (Header Branch)
for Heat Pump System (2-Pipes Connection)
MH-NP224A
MH-NP288A
5.7.6
Multi-Kit (Header Branch)
for Heat Recovery System (3-Pipes Connection)
MH-NP288X
5.8 Control —
5.8.1 3 Pin Connector Cable PCC-1A
5.8.2 Remote Sensor THM-R2A
5.8.3 Relay and 3 Pin Connector Kit PSC-5RA
