CONTROL SYSTEM
6-14
TC-15001-rev.3
Model Number CIS01
Model Type 6LPSOL¿HG:LUHG&RQWUROOHU
Setting On/Off
Mode
Temp.
Fan Speed
Louver Angle
Automatic Reset of Setting Temperature
Limit for Setting Temperature
 6LPSOL¿HG:LUHG&RQWUROOHU
6.3.1 Features and Functions
 6SHFL¿FDWLRQV
Model CIS01
Outer Dimension
<W × H × D>
2-3/4 × 4-23/32 × 43/64 inch
(70 × 120 × 17 mm)
Net Weight /%6NJ$SSUR[
Installation Location Indoor Use
Installation Method Wall-embedded using steel box (option)
Ambient Temperature 41 to 95°F (5 to 35°C)
Ambient Humidly 35 to 90%
6.3.3 Dimensions
