Johnson Controls (H,Y,C)IDM012B21S User Manual

INDOOR UNITS
TC-15001-rev.3
3-43
3.1.5.8 Electrical Data
VOL: Rated Unit Power Supply Voltage (V)
PH: Phase
HZ: Frequency (Hz)
MCA: Minimum Circuit Ampacity (A)
MFA: Maximum Fuse Ampacity (A)
237 5DWHG0RWRU2XWSXWN:
FLA: Full Load Ampacity (A)
Model
Unit Main Power Applicable Voltage Power Supply
Indoor
Fan Motor
Unit
VOL PH HZ Maximum Minimum MCA MFA OPT FLA
(H,Y)IDS006B21S
208/230 1 60 253 188
0.20 5 0.04 0.16
(H,Y)IDS008B21S 0.20 5 0.04 0.16
(H,Y)IDS012B21S 0.20 5 0.04 0.16
(H,Y)IDS015B21S 0.29 5 0.06 0.23
(H,Y)IDS018B21S 0.29 5 0.06 0.23
NOTE:
3RZHUVXSSO\YROWDJHVKRXOGEHVDWLV¿HGZLWKWKHIROORZLQJ
Supply Voltage: Rated Voltage within ±10%
Starting Voltage: Rated Voltage within -15%
Operating Voltage: Rated Voltage within ±10%
