OPTIONAL PARTS
5-4
TC-15001-rev.3
5.2.3 Snow Protection Hood
Ɣ,QVWDOODWLRQ$SSHDUDQFH
• Top Flow Type 72,000 Btu/h
No. Item Model
1 Hood for Air Outlet ASG-TP20FAS1
2 Hood for Rear Side Air Inlet ASG-TP20BAS1
3 Hood for Left Side Air Inlet ASG-TP20LS2
4 Hood for Right Side Air Inlet ASG-TP20RS2
5
Safety Wire Rope
to Prevent Overturning
(Field-Supplied)
௅
Applicable Outdoor Unit
Model
Top Flow Type
72,000 Btu/h
Top Flow Type
96,000 and 120,000 Btu/h
Hood for Air Outlet ASG-TP20FAS1 ASG-TP20FBS1
Hood for Rear Side Air Inlet ASG-TP20BAS1 ASG-TP20BBS1
Hood for Left Side Air Inlet ASG-TP20LS2
Hood for Right Side Air Inlet ASG-TP20RS2
Available Combinations
Unit: inch (mm)
Front Side Right Side
Rear Side
(View from P)
Airflow Direction
(Front Side)
Airflow Direction
(Rear Side)
