INDOOR UNITS
TC-15001-rev.3
3-79
3.3.9 Electrical Data
VOL: Rated Unit Power Supply Voltage (V)
3+ 3KDVHij
HZ: Frequency (Hz)
MCA: Minimum Circuit Ampacity (A)
MFA: Maximum Fuse Ampacity (A)
OPT: Rated Motor Output (kW)
FLA: Full Load Ampacity (A)
Model
Unit Main Power Applicable Voltage Power Supply
Indoor
Fan Motor
Unit
VOL PH HZ Maximum Minimum MCA MFA OPT FLA
(H,Y)IC1006B21S
208/230 1 60 253 188
0.2 15 0.050 0.2
(H,Y)IC1008B21S 0.3 15 0.050 0.2
(H,Y)IC1012B21S 0.4 15 0.050 0.3
(H,Y)IC1015B21S 0.5 15 0.050 0.4
NOTE:
3RZHUVXSSO\YROWDJHVKRXOGEHVDWLV¿HGZLWKWKHIROORZLQJ
Supply Voltage: Rated Voltage within ±10%
Starting Voltage: Rated Voltage within -15%
Operating Voltage: Rated Voltage within ±10%
