OPTIONAL PARTS
5-10
TC-15001-rev.3
< Hood for Left Side Air Inlet and Right Side Air Inlet (72,000 ~ 120,000 Btu/h) >
Unit: inch (mm)
• Hood for Left Side Air Inlet
• Hood for Right Side Air Inlet
: Installation Dimension
No. Item Qty.
1 Right Side Plate 1
2 Left Side Plate 1
3 Faceplate (Top Side) 1
4 Faceplate (Bottom Side) 1
Details of A
Details of B
Details of A
Details of B
