Johnson Controls (H,Y,C)IDM012B21S User Manual

OPTIONAL PARTS
5-12
TC-15001-rev.3
Specifications
Model
Item
Applicable Indoor Unit Duct High Static Type Duct High Static Type Duct Slim Type Duct Slim Type
[(H,Y)IDH**B21S] [(H,Y)IDH**B21S] [(H,Y)IDS**B21S] [(H,Y)IDS**B21S]
024 to 030 036 to 048 006 to 012 015 to 018
Quantity per unit 1
Air Flow cfm 741 741 741 741
(m
3
/min)
(21) (21) (21) (21)
Initial Pressure Loss in.W.G (Pa) 0.02 (5.8) 0.02 (5.8) 0.02 (5.8) 0.02 (5.8)
Filter Box Material Galvanized Steel Sheets
Color White
Filter Material P. P / Aluminum
Color Black / Sliver
Model
Item
Applicable Indoor Unit Duct Medium Static Type Duct High Static Type Duct Medium Static Type Duct Medium Static Type
[(H,Y)IDM**B21S] [(H,Y)IDH**B21S] [(H,Y)IDM**B21S] [(H,Y)IDM**B21S]
Duct Medium Static Type
006 to 012 015 to 018 024 to 030 036 to 048
Quantity per unit 1
Air Flow cfm 741 741 741 741
(m
3
/min)
(21) (21) (21) (21)
Initial Pressure Loss in.W.G (Pa) 0.02 (5.8) 0.02 (5.8) 0.02 (5.8) 0.02 (5.8)
Filter Box Material Galvanized Steel Sheets
Color White
Filter Material P. P / Aluminum
Color Black / Sliver
kBtu/h
[(H,Y)IDM**B21S]
KW-PP3Q KW-PP4Q KW-PP5Q KW-PP6Q
kBtu/h
KW-PP7Q KW-PP8Q KW-PP9Q KW-PP10Q
NOTES:
5HPRYHWKHPRXQWLQJÀDQJHRQWKHLQGRRUXQLW7KHQLQVWDOOWKHVXFWLRQÀDQJHZLWKWKHDLU¿OWHU
:KHQVHUYLFLQJRUPDLQWDLQLQJUHPRYHWKHKROGHURUVLGHSODWH7KHQUHPRYHWKHDLU¿OWHU
&OHDQWKHDLU¿OWHUE\YDFXXPLQJGXVWRUFOHDQZLWKZDWHURUDQHXWUDOGHWHUJHQW
$LUÀRZ
MBH
MBH
$LUÀRZ
