FEATURES
TC-15001-rev.3
1-25
Ŷ :DOO0RXQW7\SH0RGHOV
 7,:0%6WR7,:0%6
Ɣ(DV\0DLQWHQDQFHDQG)OH[LEOH'HVLJQ
(1) Face panel
The unit has been designed with a face panel and a slim body. The front panel is easy to clean and
should remain relatively dust free. It is easily removed and washed with water.
&RPSDFWGHVLJQZLGWKRILQFKPP2QO\IRU7,:0%6DQG7,:0%6
The compact design width of 31-3/32inch (790mm) makes it possible to install in a narrow space.
(3) Applicable to centralized control
When each indoor unit is controlled with a wireless controller, there is no need to install a wired
controller with a centralized control system.
Ɣ(DV\,QVWDOODWLRQ
',3VZLWFKVHWWLQJZLWKRXWUHPRYLQJWKHIURQWSDQHO
Other switch settings can be performed without removing the front panel.
 2SHQWKHHOHFWULFDOER[FRYHUDQGSHUIRUPWKH¿HOGHOHFWULFDOZLULQJZRUNZLWKRXWUHPRYLQJWKHIURQW
panel.
(2) Operation control with wireless controller
Each unit can be controlled with a wireless controller by
built-in receiver kit. A wired controller is also available
instead of a wireless operation.
A signal-receiving buzzer and indicator light signals the
wireless controller operation.
In an instance of group control with a wireless controller
(multiple units are controlled simultaneously with one
wireless controller), an optional receiver kit or wired
controller is required.
31-3/32inch (790mm)
Electrical Box Cover
PCB for DIP Switch
Remove the DIP switch
cover to set the DIP
switches.
Open the front cover
to see the electrical box
Remove the electrical box cover
to perform the on-site wiring work
of the terminal block.
A
vailable Range for Wireless Controlle
r
CS-NET
New Type
Beep
