134 IFC-3030 Programming Manual — P/N 52025:C 08/05/2005
Type Codes Type Codes for Input Devices
G.3 Type Codes for Input Devices
G.3.1 Overview
This section provides a list of Type Codes for intelligent detectors and for monitor modules. The
following Point Types light an LED at the panel when activated.
• fire alarm - lights the FIRE ALARM LED
• supervisory - lights the SUPERVISORY LED
• security - lights the SECURITY LED
• trouble - lights the TROUBLE LED
G.3.2 Type Codes for Intelligent Detectors
Following is a list of intelligent detector Type Codes, which specify the type of detector installed at
an SLC address.
Table G.1 Intelligent Detector Type Codes
Point Characteristics
Type Code Point Type Latching
(Y=yes
N=no)
Activates
CBE
Device/Point Function
SMOKE (ION)
fire Y Y Ionization smoke detector
SUP L(ION)
*
supervisory Y Y Ionization smoke detector
SUP T(ION)*
†
supervisory N Y Ionization smoke detector
SMOKE(DUCTI)
fire Y Y Duct Ionization smoke detector
SUP L(DUCTI)
supervisory Y Y Duct ionization smoke detector
SUP T(DUCTI)†
supervisory N Y Ionization smoke detector used as a duct detector to report
supervisory condition rather than alarm.
SMOKE(PHOTO)
fire Y Y Photoelectric smoke detector
SUP L(PHOTO)*
supervisory Y Y Photoelectric smoke detector
SUP T(PHOTO)*†
supervisory N Y Photoelectric smoke detector
SMOKE(DUCTP)
fire Y Y Duct Photoelectric smoke detector
SUP L(DUCTP)
supervisory Y Y Photoelectric smoke detector used as a duct detector to report
supervisory condition rather than alarm
SUP T(DUCTP)†
supervisory N Y Photoelectric smoke detector used as a duct detector to report
supervisory condition rather than alarm.
RFSMOKE(PHOTO)
fire Y Y Wireless Photoelectric smoke detector
SMOKE(HARSH)
fire Y Y HARSH smoke detector
SMOKE(LASER)
fire Y Y Laser smoke detector
SUP T (LASER)*†
supervisory N Y Laser Smoke Detector
SUP L (LASER)*
supervisory Y Y Laser Smoke Detector
AIR REF
fire Y Y Assign to one or more
7351J detectors used to monitor the quality of
air entering the protected area. The air quality measurement allows
the
VIEW® system to compensate for vehicle fumes, fog, or other
particles brought into the protected area through the ventilation
system. Poor air quality will lower the sensitivity of all
7351J detectors
on the SLC. The detector sensitivity, however, remains within
approved limits (always less than 1% obscuration per foot).
Note: A reference detector still functions as a smoke detector, but the detector sensitivity level should be set to the least sensitive level—AL:9 and
PA:9 Alarm and Pre-Alarm sensitivity. Refer to “Detector Sensitivity Settings” on page 119 for a complete list of detector sensitivity settings.
HEAT
fire Y Y 190
o
F heat detector
HEAT+
fire Y Y 190
o
F heat detector with low temperature warning
HEAT(FIXED)
fire Y Y 135
o
F intelligent thermal sensor
HEAT (ROR)
fire Y Y 15
o
F per minute rate-of-rise detector
SMOKE ACCLIM
fire Y Y Combination Photoelectric/heat detector
SMOKE(ACCLI+)
fire Y Y Combination Photoelectric/heat detector with low temperature
warning
SMOKE(MULTI)
‡
fire Y Y Multisensor smoke detector
SMOKE(BEAM)
fire Y Y Beam Smoke Detector
* Use only with approval of AHJ
† Not suitable for Canadian applications
‡ CLIP Mode only
