IFC-3030 Programming Manual — P/N 52025:C 08/05/2005 37
Point Program Program
The cursor will appear in the date fields, and may be moved using the keyboard arrow keys. Type to
add/edit any holiday dates.
SOFT KEYS
ANY YEAR: Press to place asterisks in the YY section of the field. An asterisk denotes any year.
NEXT/PREVIOUS SELECTION: Press to view the next or previous group of five holidays.
ACCEPT: Press to save changes to the date fields and to return to the Panel Program Menu.
3.4 Point Program
The Point Program allows the programmer to enter/change point information for detectors,
modules, panel circuits, and general, releasing, logic and trouble zones.
Press the Point Programming Menu soft key of the Program/Alter Status Menu to display the
screen below.
Figure 3.23 Point Program Menu
Soft Keys
POINT SELECT: Press until the desired point type appears. The types - detector, module, panel
circuit module, general zone, logic zone, trouble zone, or ACS Board - appear in the parenthesis
after the point formats. Enter the desired point address in the format field.
ACCEPT: Press to progress to the appropriate screen, based on the type of point selected.
NEXT/PREVIOUS SELECTION: Press to scroll backward or forward to the next or previously
installed point.
POINT PROGRAM MENU
POINT SELECT:
LyyDzzz (DETECTOR)
NEXT POINT ACCEPT
PREVIOUS POINT BACK
