1. Specification
JAX-9B W-FAX Installation Manual
1
7ZPNA4096
1.3. Components
Table of Components for Weather Facsimile Receiver
No. Name Type Quantity
Mass
1Unit (kg)
Remarks
Standard Components
1 Weather facsimile receiver JAX-9B 1 5.3
with a recording paper for testing
2 Protective cover MTT312734 1 0.08
3 Coaxial connector M-P-7 1 0.02
for antenna cable
4 Power supply connector
721-103/037-000
1 0.01
Terminal block for DC power supply
5 External I/F connector
8213BFK/8TOP
K(25.840.0853.0)
1 0.02
Terminal block for AF signal, BK
signal and GPS data
6 Label in Japanese MPNN32192 1 0.01 Switch name label for Japanese
7 Spare parts 7ZXNA4003 1 0.04
Fuse (5A, 8A) Four pieces each
Instruction Manual (JPN) 7ZPNA4035 0.3
with Operation Card
(7ZPNA4102)
8
Instruction Manual (ENG) 7ZPNA4036
1
0.3
with Operation Card
(7ZPNA4103)
Options
9 Rectifier unit NBA-5143 1 3.5
10 PC Interface kit 7ZZNA4016 1 0.2
Terminal Block (TB103)
for connecting PC, Cable clamp
11 FAX image display kit 7ZZNA4017 1 1
PC software for displaying image
Communication I/F Unit
12 Junction box JQD-69C 1 1
Cable insertion 12mm diameters
13 Whip antenna (L=6MT) NAW-60 1 3.5
6m
14 Recording paper 6ZPTS00108 ______ 0.4
NOTE
JAX-9B is shipped with a test recording paper roll and the antenna connector fitted in it.
The rectifier unit makes 100VAC or 220VAC power supply available to JAX-9B.
