3. Wiring
JAX-9B W-FAX Installation Manual
28
7ZPNA4095
3.6. Connection to Remote Maintenance server (Option)
VDR
JAX-9B Terminal TB103
1
9
TB103
7pin
VDR JCY-1800
Remote Maintenance System
8pin 9pin
Shield Rx- Rx+
