1. Specification
JAX-9B W-FAX Installation Manual
7
7ZPNA4096
1.9. Specifications of JAX-9B
1.9.1. Facsimile functional ability
1) Recording system : Solid-state recording by thermal head
2) Recording paper : Thermo-sensitive recording paper
260mm (width) x 25m (length) / roll
3) Effective recording width : 256mm (10 inches)
4) Index of cooperation : 576 or 288
5) Scanning speed : 60, 90,120,240 SPM (Scanning / Minutes)
6) Scanning resolution : 8dots/mm
7) Scanning line density : Approx. 7lines/mm, 3.5lines/mm
8) Phase matching : Automatic and manual
9) Halftone recording : 16 levels by Dither pattern
10) Negative/Positive recording : Manual
11) External receiver connection : 0dBm, 600Ω (1900Hz +400Hz / -400Hz)
12) Operation modes : ▪ Automatic recording
All the operation of IOC selection, scan speed selection, phase
matching, recording, paper feed and stop are controlled by the
remote control signals in accordance with the WMO Technical
specifications.
▪ Manual recording
The IOC and scan speed are manually selected and phase
matching, recording and stop are automatically controlled
▪ Forced recording
All the operations are manually preset.
▪ Timer program recording
Recording starting time and finishing time can be programmed.
13) Timer Program channels : 15 channels
14) Setup data list recording : Receiving frequency list, Timer Program channel list
15) Self-test function : Recording test, Panel test
16) Automatic time correction : Input the GPS data
17) Image data output : Display received image on PC
18) Remote maintenance : Connecting to the JRC Remote Maintenance System
