7. Outline drawing
JAX-9B W-FAX Installation Manual
48
7ZPNA4095
7.2. Rectifier Unit NBA-5143
NBA-5143
ＪＲＣ
2A
AC IN
DC24V OUT
－＋
COM
100V 220V
FG
MADE IN JAPAN
COVER
110±2
140±2
PAINTING COLOR : N4 (Munsell)
MASS : 3.5kg
126±1 77
4-φ5
（Unit:mm）
