3. Wiring
JAX-9B W-FAX Installation Manual
26
7ZPNA4095
3.4. Power supply wiring when connecting to AC power supply (Option)
1
3
NBA-5143
ＪＲＣ
2A
AC IN
DC24V OUT
－＋
COM
100V 220V FG
1：Red
2：Blue
3：Green
AC IN
COM
100V
220V
AC power supply
220Vac
AC power supply
100Vac
TB101
