JRC JAX-9B User Manual

3. Wiring
JAX-9B W-FAX Installation Manual
24
7ZPNA4095
3.2. Cable
No. Signal Cable JIS type Remark
1 AC Power 2 x 1.5mm
2
DPYC-1.5
2 x 1.5mm
2
DPYCS-1.5 Shield type
2 DC Power 2 x 1.5mm
2
DPYC-1.5
2 x 1.5mm
2
DPYCS-1.5 Shield type
3 Antenna RG-10/U
50Ω impedance
RG-10/UY Shield type
RG-12/U
75Ω impedance
RG-12/UY Shield type
4 Earth for Junction Box 1 x 1.5mm
2
SPYC-1.5
5 External receiver (AF signal) 1X2X0.75mm
2
TTYCS-1
6 BK 1X2X0.75mm
2
TTYCS-1
7 GPS receiver 1X2X0.75mm
2
TTYCS-1 NME input
8 FAX image data 4X2X0.75mm
2
TTYCS-4 RS-422
9 RMS data 1X2X0.75mm
2
TTYCS-1 NMEA output
