1. Specification
JAX-9B W-FAX Installation Manual
8
7ZPNA4095
1.9.2. Synthesized Receiver
1) Receiving system : Phase-locked type frequency synthesized with up-conversion
and double super heterodyne type
2) Class of emission : F3C
3) Frequency range : 2.0000 - 24.9999 MHz
4) Automatic frequency selection : The optimal frequency is selected automatically.
5) Receiving frequency memory : Up to 90 channels storing
6) Sensitivity : 2μV (+6dBμ) or less
for antenna input to obtain the output of -5dBm at 20dB S/N
7) IF Selectivity : 6dB down point 2.4 kHz to 3.0 kHz
66dB down point 6 kHz or less
8) Image rejection ratio : More than 60dB
1.9.3. General Specifications
1) Power voltage : 12 / 24 / 32 Vdc -10% to +30%
100 / 220 Vac with Rectifier unit (Option)
2) Power consumption : 50VA or less
3) Dimensions : 358 (W) x 254 (D) x 107 (H) mm (Including the mounting base)
4) Mass : Approx. 5.3 kg (Including the mounting base)
5) Color : N4 (Munsell)
1.9.4. Environmental Condition
1) Operating temperature : Operating range -15
o
C to +55
o
C
(The print density might become light when using it under -10
o
C or
less.)
1.9.5. Rectifier Unit
Input
1) Power voltage : 100Vac / 220Vac, Selectable by connecting to terminal pins
2) Frequency : 50 / 60Hz
Output
3) Power voltage : 24Vdc
4) Voltage deviation : ±10% less than
5) Electrical Current : 1.67A
