4. Operation 40
Setting System Output
・Make SYSTEM a yellow display, press or the [ENT] key, and select it from the following, set content.
Set content ：OFF/ON
OFF ：Maintenance system information is not output with the constant period.
ON ：
Maintenance system information is added to the depth output port and it outputs.
・Select the content by and press the [ENT] key.
Setting Printer Port Output
・Make PRINTER PORT OUT a yellow display, press or the [ENT] key, and select it from the following,
set content.
Set content ：PRINTER/PC
PRINTER ：
The signal for the printer control is output.
PC ：Maintenance system information is output to the printer port.
The output content follows the setting of menu “PRINTER CONT>PRINT MODE".
(Refer to 4.6 Printer Control Setting.)
・Select the content by and press the [ENT] key.
Maintenance menu operation is written in “6.2 Maintenance Function”
4.8 Master Reset
The buzzer sounds when turning on the power while pressing the [MENU] key and the [CLR] key at the
same time and master reset is executed. All set values except the date and time return to the factory
shipment value.
When master reset is completed, the following screen is displayed.
Please do connection setting of transducers.
A primary transducer is set on this screen. When the [ENT] key is pressed after the frequency of the
connected transducer is selected, it changes into the primary transducer setting menu of the initial setting
menu.
Refer to 4.5 Initial Setting on page 27 for the following setting methods.
When turning on the power for the first time after installing it, this screen is displayed.
To Next Page
