No. Item Description Level Setting range Default
P01 Maximum sewing speed The maximum sewing speed reached by fully depressing the
pedal is set with this function setting item. The maximum sewing
speed can be changed within the sewing speed range specied
for [P68 Maximum sewing speed].
* The maximum sewing speed can also be changed using the +
- switch on the operation panel.
U 100-[P68]
(sti/min)
MS
：
4000
SH
：
3500
P02 Tilt of the pedal Change in the sewing speed with respect to the depressing depth
of the pedal is set with this function setting item.
The sewing speed is increased abruptly when this parameter is
set to a large value, or increased slowly when this parameter is
set to a small value.
S 10-100(%) 80
P04 Reverse feed stitching
speed at the beginning of
sewing
The sewing speed to be used during the reverse feed stitching at
the beginning of sewing is set with this function setting item.
U 100-3000
(sti/min)
1900
P05 Reverse feed stitching
speed at the end of sewing
The sewing speed to be used during the reverse feed stitching at
the end of sewing is set with this function setting item.
U 100-3000
(sti/min)
1900
P06 Overlapped stitching speed The sewing speed to be used during the overlapped stitching is
set with this function setting item.
* This speed can also be changed using the relevant switch on
the operation panel.
U 100-3000
(sti/min)
1900
P07 Sewing speed for soft start The sewing speed for soft start at the beginning of sewing is set
with this function setting item.
U 100-1500
(sti/min)
800
P08 Soft start function The number of stitches to be sewn with the soft-start function at
the beginning of sewing is set with this function setting item.
0: The soft-start function is not selected
1 - 9: The number of stitches to be sewn with the soft-start func-
tion
U 0-99
(Stitches)
1
P09 Sewing speed for the polyg-
onal-shape stitching
Sewing speed for the polygona-shape stitching is set with this
function setting item.
* The sewing speed can also be changed using the + - switch on
the operation panel.
U 200-[P68]
(sti/min)
MS
：
4000
SH
：
3500
P10 Setting of the reverse feed
stitching at the end of end of
polygonal-shape stitching
Whether the reverse feed stitching is automatically carried out
at the end of polygonal-shape stitching is set with this function
setting item.
ON: Reverse feed stitching is automatically performed at the
end of sewing
OFF: Sewing machine stops sewing before starting reverse
feed stitching at the end of sewing. It performs reverse feed
stitching when the front part of pedal is depressed.
U ON/OFF ON
P12 Changeover of the reverse
feed stitching at the start
of sewing between Auto /
Manual
The sewing speed for the reverse feed stitching at the beginning
of sewing is set with this function setting item.
0: The reverse feed stitching is performed by manually operating
the pedal.
1: The reverse feed stitching is performed at the sewing speed
set with [P04 Reverse feed stitching speed at the beginning of
sewing].
U 0-1 1
P13 Function of stop immedi-
ately after the reverse feed
stitching at the beginning of
sewing
Operation to be carried out at the end of the reverse feed stitching
at the beginning of sewing is selected with this function setting
item.
CON: The sewing machine does not stop temporarily after com-
pletion of the reverse feed stitching at the beginning of sewing
STP: The sewing machine stops temporarily after completion of
the reverse feed stitching at the beginning of sewing
U CON/STP CON
P15 Changeover of the needle
up/down correction function
The function of needle up/down correction switch is changed over
with this function setting item.
0: Needle up/down correction
1: One stitch correction
2: Continuous half stitch
3: Continuous one stitch
U 0-3 0
P16 Speed limit to reverse-feed
stitching
The speed limit applied when reverse feed stitching is carried out
is set with this function.
0: No speed limit
10 - 3000: Sewing is performed at the set sewing speed
S 0-4000
(sti/min)
0
P18 Correction of solenoid-on
timing for the reverse feed
stitching at the beginning of
sewing
Stitch alignment can be carried out by changing the timing of
actuating the reverse-feed stitching solenoid at the time of reverse
feed stitching at the beginning of sewing. When the set value for
this parameter is increased, the length of stitch at the end of A
process is increased and the length of stitch at the beginning of B
process is decreased.
U 0-200 123
P19 Correction of solenoid-o
timing for the reverse feed
stitching at the beginning of
sewing
Stitch alignment can be carried out by changing the timing of
releasing the reverse-feed stitching solenoid at the time of reverse
feed stitching at the beginning of sewing. When the set value for
this parameter is increased, the length of stitch at the beginning of
B process is increased.
U 0-200 130
＊
P21 Low-speed section by pedal Start position of sewing by operating the pedal is set with this
function setting item.
S 30-1000 520
＊
P22 Sewing starting position by
pedal
Releasing position of pedal operation is set with this function
setting item.
S 30-1000 420
＊
P23 Position to lift the presser
foot by pedal
The position to lift the presser foot by operating the pedal is set
with this function setting item.
S 30-1000 270
＊
Do not change the set values with asterisk (*) mark as they are functions for maintenance. If the standard set value set at the time
of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated. If it is necessary to
change the set value, please purchase the Engineer’s Manual and follow the instructions.
– 37 –
4-9. Function setting list
