4-14. About the USB
The USB connectors are equipped on upper section
of the operation panel and electrical box
.
To use a USB thumb drive, remove connector cover
and insert the USB thumb drive into the USB con-
nector.
* In the case a USB thumb drive is not used, the
USB connector should be protected with connec-
tor cover
without exceptions.
If dust or the like enters the USB connector, a fail-
ure can be caused.
[Insertion position of the USB thumb drive]
WARNING :
The device to be connected to the USB port should have the rated current value or less as shown
below.
If any device rated current value of which is higher than the rated current value, the main body of the
sewing machine or the USB device connected can be damaged or malfunction.
Rated current value of the USB port
USB port on the electrical box side: Maximum rated current value of 1 A
USB port on the operation panel side: Maximum rated current value of 0.5 A
– 51 –

Table of Contents

Other manuals for JUKI DDL-8000A

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the JUKI DDL-8000A and is the answer not in the manual?

JUKI DDL-8000A Specifications

General IconGeneral
Stitch TypeLockstitch
Motor TypeDirect-drive motor
Thread TrimmerAutomatic
Max. Stitch Length5mm
Needle Bar Stroke30.7mm
Lift of the Presser FootBy hand: 5.5mm, By knee: 13mm
Control PanelDigital
LubricationAutomatic
