5-4. Adjusting the main shaft stop position
If the position of the marker line (blue) on the handwheel is too far from the position of the
marker line (blue) on the cover after thread trimming, machine head angle should be adjusted
following the steps of procedure described below.
1) The function setting screen is displayed
by keeping
󱢵
held pressed for
three seconds on the normal sewing
state.
2) Press
❼
to ash function
setting No.
A
on and o󰀨. In this state,
press
❻
to select parame-
ter P72.
3) Turn handwheel in the normal direction
of rotation to align marker line
A
on
the electrical box cover with marker
line
B
on the handwheel.
4) Press
❽
to determine the set-
ting.
5) Press
󱢵
to return the sewing
machine to the sewing state.
– 59 –

JUKI DDL-8000A Specifications

General

Stitch Type	Lockstitch
Motor Type	Direct-drive motor
Thread Trimmer	Automatic
Max. Stitch Length	5mm
Needle Bar Stroke	30.7mm
Lift of the Presser Foot	By hand: 5.5mm, By knee: 13mm
Control Panel	Digital
Lubrication	Automatic
