No. Item Description Level Setting range Default
P73 Adjustment mode for the
needle-down stop angle
The current main shaft angle is always displayed in the data
display section. When you turn the pulley to bring the main shaft
to the needle-down stop position and press the enter switch, the
only the needle-down angle of the main shaft is automatically set.
S 0-1439
(1/4°)
＊
P74 Back-tack solenoid OFF
parameter
Back-tack solenoid OFF parameter
* Refer to the explanation of operation of the BT solenoid in the
Engineer's Manual for details.
S 0-990 3
＊
P75 Back-tack solenoid OFF
parameter
Back-tack solenoid OFF parameter
* Refer to the explanation of operation of the BT solenoid in the
Engineer's Manual for details.
S 0-990 10
＊
P76 Back-tack solenoid ON
parameter
Back-tack solenoid ON parameter
* Refer to the explanation of operation of the BT solenoid in the
Engineer's Manual for details.
S 10-990 200
P77 Back-tack solenoid ON
timing at the end of sewing
The BT solenoid ON timing at the end of sewing is set with this
function setting item.
* This parameter applies only to the free stitching.
U 50-500 150
P78 Thread clamp ON angle ON-angle of the thread clamp is set with this function setting item. U 0-359
(°)
220
P79 Thread clamp OFF angle OFF-angle of the thread clamp is set with this function setting
item.
U 0-359
(°)
300
P87 Wiper operating time The time during which the wiper is turned ON is set with this func-
tion setting item.
S 10-990(ms) 50
P93 Reaction time when the
back part of pedal is de-
pressed
The reaction time required to start lifting of the presser foot after
the back part of the pedal is depressed is set with this function
setting item.
S 10-990(ms
)
100
P109 Wiper operation timing The waiting time required until the wiper starts operation after the
sewing machine stops with its needle up.
S 5-990 5
P110 Waiting time until the sewing
machine starts next sewing
The waiting time required until the sewing machine starts next
sewing after the thread trimming solenoid is turned OFF.
S 0-250 100
P112 Needle-up stop angle The angle from the upper dead point of needle to the needle-up
stop position is set with this function setting item.
S −359 - 359
(
°
)
−55
P113 Bobbin counter The largest value that the bobbin counter can count is set with
this function setting item. When the counter reaches that value, it
stops counting.
U 0-9999
(10 stitches)
500
＊
P114 Reverse feed solenoid oper-
ation stopping angle (start)
The angle at which the solenoid output is prohibited (start) after
pressing the reverse-feed stitching on the way switch.
S 0-359
(
°
)
262
＊
P115 Reverse feed solenoid oper-
ation stopping angle (end)
The angle at which the solenoid output is prohibited (end) after
pressing the reverse-feed stitching on the way switch.
S 0-359
(
°
)
112
P116 Function of prohibiting the
correction operation after
turning the handwheel by
hand
The correction stitching function when turning the pulley by hand
upon completion of the polygonal-shape stitching is set with this
function setting item.
0: Correction sewing function is enabled
1: Correction sewing function is disabled
U 0-1 0
P117 Thread trimming operation
after turning the handwheel
by hand
The thread trimming operation after turning the pulley by hand to
move the sewing machine from the upper and lower positions is
set with this function setting item.
0: Thread trimming operation is carried out after turning the
pulley by hand
1: Thread trimming operation is not carried out after turning the
pulley by hand.
U 0-1 1
P118 Setting of the needle up/
down switch operation after
thread trimming
The operation of the needle up/down switch after thread trimming
is set with this function setting item.
0: Needle up/down operation is carried out
1: One-stitch operation is carried out
U 0-1 0
P128 Number of condensation
stitches at the beginning of
sewing
The number of condensation stitches at the beginning of sewing
is set with this function setting item.
U 0-5(stitches) 0
P129 Number of condensation
stitches at the end of sewing
The number of condensation stitches at the end of sewing is set
with this function setting item.
U 0-5(stitches) 0
P130 Condensation stitching
speed at the end of sewing
The sewing speed for condensation stitching at the end of sewing
is set with this function setting item.
U 100-1900
(sti/min)
310
P131 Condensation stitching
speed at the beginning of
sewing
The sewing speed for condensation stitching at the beginning of
sewing is set with this function setting item.
U 0-1900
(sti/min)
310
＊
P132 Condensation solenoid
operation starting duty
ON duty of the condensation solenoid when it starts operation is
set with this function setting item.
S 1-80(%) 55
＊
P133 Condensation solenoid duty
while it is in operation
The duty of the condensation solenoid while it is in operation is
set with this function setting item.
S 1-80(%) 10
＊
P134 Condensation solenoid
operation starting time
The operation starting time for the condensation solenoid is set
with this function setting item.
S 10-150(ms) 115
＊
P135 Condensation solenoid
operation starting angle
The operation starting angle for the condensation solenoid is set
with this function setting item.
S 10-359
(
°
)
75
P136 Selection of the presser foot
operation when the power is
turned ON
Operation of the presser foot when the power is turned ON is
selected with this function setting item.
0: The presser foot does not operate (It operates when the back
part of the pedal is depressed.)
1: The presser foot goes up after automatically retrieving the
origin
2: The presser foot comes down after automatically retrieving
the origin
U 0-2 0
＊
Do not change the set values with asterisk (*) mark as they are functions for maintenance. If the standard set value set at the time
of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated. If it is necessary to
change the set value, please purchase the Engineer’s Manual and follow the instructions.
– 39 –
