69
3) Set the items below in the second screen.
■The second screen of sewing common data setting
4 5 6
4 5 6 7
7
8
2) Set the items below in the first screen.
1 : Limiting procedure of max. zigzag width limitation
For the limiting procedure of max. zigzag width
limitation, there are two settings below.
2 : Max.zigzag width limitation value
* Display varies according to the procedure selected
in 1.
1) When the center is set in 1 :
Max.zigzag width limitation value (center)
2) When the left/right is set in 1 :
Max.zigzag width limitation value (right)
Max.zigzag width limitation value (left)
3: Reference of stitch base line
For the reference of stitch base line,
there are three settings below.
1) Center
2) Right
3) Left
(1) Sewing common data
1) Press 2 in the information screen.
■The first screen of sewing common data setting
1 2 3
1 2 3
4 : Mirror function setting
Mirror inversion means the function that the reverse pattern stitching is performed after pressing the
mirror inversion switch during temporary stop of sewing.
The sewing patterns that the mirror inversion is possible are scallop, custom, continuous stitching and
cycle stitching.
For the mirror inversion, there are two settings below.
1) Center
2) Left/right
8
To Next Page
