Art. No. SC 1000 KNX
o Position the decorative frame (17) on the supporting ring.
Assembling and connecting push-button extension module...
o Guide the connection cable of the push-button extension module (25) between the
supporting frame and frame.
o Fix push-button extension module (26) to supporting frame using the plastic screws (27)
enclosed. Tighten the screws only lightly.
o Insert the pushbutton extension module connecting cable in correct position into the
connection point of the communication module on the Smart Control (11) (figure 2). When
doing so, ensure that the connecting cable is not pinched.
o Mount the module control surfaces on the push-button extension module.
Connect the external power supply...
The Smart Control needs an external DC power supply for supplying the device electronics
(figure 4). It is not possible to use the unchoked output of KNX power supplies as device power
supply! The power supply must be provided by an additional device (e.g. RMD or UP DC power
supply) (see accessories).
o Connect power supply to terminal (18) and insert into connection (9) (figure 2). Comply with
the polarity!
Completing installation...
o Connect the KNX bus cable to the bus connection of the communication module.
o Insert the Smart Control with the communication module carefully into the supporting frame
and lock into place. Ensure that no cables are squashed.
