Jung Smart Control SC 1000 KNX User Manual

Art. No. SC 1000 KNX
Function: Status LED in case of push button function
Object
h
36
Function
Status LED
Name
B.Module button
1
1,2
Type
1 byte
DPT
5.xxx,
6.xxx,
20.102
Flag
C, W, -, (R)
3
Description 1-byte object for activation of the status LED.
Objects for alarm message
Function: Alarm signal
Object
h
56
Function
Switching
Name
B.Alarm message
Type
1-bit
DPT
1.xxx
Flag
C, W, -, (R)
3
Description 1-bit object for the reception of an alarm signalling (polarity configurable).
Function: Alarm signal
Object
h
57
Function
Switching
Name
B.Alarm message
acknowledge
Type
1-bit
DPT
1.xxx
Flag
C, -, T, (R)
4
Description 1-bit object for transmitting the acknowledgement of an alarm signalling
(polarity configurable).
1: The number of rockers or buttons depends on the planned device variant.
2: The objects have been described for rocker 1 or button 1 as an example. The objects for the
other rockers/buttons are defined in the same way by shifting the object number and changing
the object name.
3: For reading, the R-flag must be set. The last value written to the object via the bus will be
read.
4: For reading, the R-flag must be set. The last value written to the object via the bus or by the
device will be read.
Page 31 of 347
Software "Smart Control 501511"
Object table
