Jung Smart Control SC 1000 KNX User Manual

Art. No. SC 1000 KNX
Objects for status LED
Function: Status LED in case of rocker function
Object
h
36
Function
Status LED top
Name
B.Module
rocker 1
1,2
Type
1-bit
DPT
1.xxx
Flag
C, W, -, (R)
3
Description 1-bit object for activation of the status LED.
Function: Status LED in case of rocker function
Object
h
36
Function
Status LED top
Name
B.Module
rocker 1
1,2
Type
1 byte
DPT
5.xxx,
6.xxx,
20.102
Flag
C, W, -, (R)
3
Description 1-byte object for activation of the status LED.
Function: Status LED in case of rocker function
Object
h
37
Function
Status LED bottom
Name
B.Module
rocker 1
1,2
Type
1-bit
DPT
1.xxx
Flag
C, W, -, (R)
3
Description 1-bit object for activation of the status LED.
Function: Status LED in case of rocker function
Object
h
37
Function
Status LED bottom
Name
B.Module
rocker 1
1,2
Type
1 byte
DPT
5.xxx,
6.xxx,
20.102
Flag
C, W, -, (R)
3
Description 1-byte object for activation of the status LED.
Function: Status LED in case of push button function
Object
h
36
Function
Status LED
Name
B.Module button
1
1,2
Type
1-bit
DPT
1.xxx
Flag
C, W, -, (R)
3
Description 1-bit object for activation of the status LED.
1: The number of rockers or buttons depends on the planned device variant.
2: The objects have been described for rocker 1 or button 1 as an example. The objects for the
other rockers/buttons are defined in the same way by shifting the object number and changing
the object name.
3: For reading, the R-flag must be set. The last value written to the object via the bus will be
read.
Page 30 of 347
Software "Smart Control 501511"
Object table
