Jung Smart Control SC 1000 KNX User Manual

Art. No. SC 1000 KNX
Function: 2-channel operation
Object
h
18
Function
Channel 2 value
Name
B.Module rocker/
B.Module button 1
1,2
Type
2 byte
DPT
9.001
Flag
C, -, T, (R)
3
Description 2-byte object for the transmission of value telegrams, if 2-channel operation is
activated.
Objects for full-surface operation with rocker function (with dimming, venetian blind and
2-channel operation)
Function: Full-surface operation
Object
h
1
Function
Switching
Name
B.Module rocker 1
Full-surface
actuation
1,2
Type
1-bit
DPT
1.xxx
Flag
C, W, T,
(R)
3
Description 1-bit object for the transmission of switching telegrams (ON, OFF) when there
is full-surface operation of an operating area.
Function: Full-surface operation
Object
h
1
Function
Scene extension
Name
B.Module rocker 1
Full-surface
actuation
1,2
Type
1 byte
DPT
18.001
Flag
C, -, T, (R)
3
Description 1-byte object for recalling or for storing one of 64 scenes max. from a scene
push button sensor in case of full-surface operation of an operating area.
1: The number of rockers or buttons depends on the planned device variant.
2: The objects have been described for rocker 1 or button 1 as an example. The objects for the
other rockers/buttons are defined in the same way by shifting the object number and changing
the object name.
3: For reading, the R-flag must be set. The last value written to the object via the bus or by the
device will be read.
4: For reading, the R-flag must be set. The last value written to the object via the bus will be
read.
Page 29 of 347
Software "Smart Control 501511"
Object table
