Art. No. SC 1000 KNX
Objects for operating mode change-over
Function: Operating mode switchover
Object
h
82
Function
Operating mode switchover
Name
C.Input
Type
1 byte
DPT
20.102
Flag
C, W, T,
(R)
1
Description 1-byte object for change-over of the operating mode of the controller
according to the KNX specification. This object is only available in this way
when the operating mode change-over is to take place over 1 byte
(parameter-dependent).
Function: Operating mode switchover
Object
h
82
Function
Comfort mode
Name
C.Input
Type
1-bit
DPT
1.001
Flag
C, W, T,
(R)
1
Description 1-bit object for change-over to the "Comfort" operating mode. This object is
only available in this way when the operating mode change-over is to take
place over 4 x 1 bit (parameter-dependent).
Function: Operating mode switchover
Object
h
83
Function
Standby mode
Name
C.Input
Type
1-bit
DPT
1.001
Flag
C, W, T,
(R)
1
Description 1-bit object for change-over to the "Standby" operating mode. This object is
only available in this way when the operating mode change-over is to take
place over 4 x 1 bit (parameter-dependent).
Function: Operating mode switchover
Object
h
84
Function
Night operation
Name
C.Input
Type
1-bit
DPT
1.001
Flag
C, W, T,
(R)
1
Description 1-bit object for change-over to the "Night" operating mode. This object is only
available in this way when the operating mode change-over is to take place
over 4 x 1 bit (parameter-dependent).
Function: Operating mode switchover
Object
h
85
Function
Frost/ heat protection
Name
C.Input
Type
1-bit
DPT
1.001
Flag
C, W, T,
(R)
1
Description 1-bit object for change-over to the "Frost / heat protection" operating mode.
This object is only available in this way when the operating mode change-over
is to take place over 4 x 1 bit (parameter-dependent).
1: For reading, the R-flag must be set. The last value written to the object via the bus or by the
device will be read.
Page 34 of 347
Software "Smart Control 501511"
Object table
