Jung Smart Control SC 1000 KNX User Manual

Art. No. SC 1000 KNX
Function: Operating mode switchover
Object
h
86
Function
Operating mode forced-
control
Name
C.Input
Type
1 byte
DPT
20.102
Flag
C, W, T,
(R)
1
Description 1-byte object for forced change-over (highest priority) of the operating mode of
the controller according to the KNX specification. This object is only available
in this way when the operating mode change-over is to take place over 1 byte
(parameter-dependent).
Function: Operating mode change-over presence detection
Object
h
87
Function
Presence object
Name
C.Input / Output
Type
1-bit
DPT
1.001
Flag
C, W, T,
(R)
1
Description 1-bit object through which a motion detector or an external presence button (e.
g. from a controller extension) can be linked to the controller. The object also
transmits the state of a presence button of the device to the bus.
Polarity: presence detected = "1", presence not detected = "0".
Function: Operating mode change-over window status
Object
h
88
Function
Windows status
Name
C.Input
Type
1-bit
DPT
1.019
Flag
C, W, -, (R)
2
Description 1-bit object for the coupling of window contacts. Polarity:
Window open = "1", window closed = "0".
Object for operating mode change-over
Function: Operating mode change-over
Object
h
89
Function
Heating / cooling change-
over
Name
C.Input
Type
1-bit
DPT
1.100
Flag
C, (W), T,
(R)
1
Description 1-bit object to transmit the automatically set operating mode of the controller to
specify the operating mode ("Heating" or "Cooling").
Object value "1" = Heating; Object value "0" = Cooling.
1: For reading, the R-flag must be set. The last value written to the object via the bus or by the
device will be read.
2: For reading, the R-flag must be set. The last value written to the object via the bus will be
read.
Page 35 of 347
Software "Smart Control 501511"
Object table
