Figure 2 on page 11 shows the front of the chassis congured with two Roung Engines. The chassis
measures 5.21 in. (13.23 cm) high, 16.92 in. (42.97 cm) wide, and 11.41 in. (28.98 cm) deep. The chassis
installs in a standard 800 mm deep open rack, 19 in. equipment racks, or telco open-frame racks. For
more informaon about the physical specicaons of the router and its components, see Table 5 on
page 15.
Figure 2: Front View of an AC-Powered ACX7348 Router
1—
ACX7300-FPC-2CD4C FPC
3—
Roung Engine
2—
AC PSMs
4—
Fixed FPC
Figure 3: Rear View of an ACX7348 Router
1—
Fan Tray
3—
Protecve Grounding Terminal
11
