Juniper ACX7348 - Page 36

Figure 13: ACX7348 DC PSM
1—
Handle
3—
Ejector lever
2—
DC input cable lug point
ACX7348 Input DC Voltage Specicaon
Table 10 on page 28 lists the specicaons for DC PSM.
Table 10: DC Power
Specicaons for ACX7348 Routers (Base Chassis with Dual RE)
Item Specicaons for ACX7348
DC input voltage Operang voltage range: 40 V through 72 V
DC input current rang 50 A (maximum), Nominal Voltage: -48 VDC to -60 VDC
Typical power consumpon 520 W (without opcs) at 50% trac load, with IMIX packet size of 1000 bytes.
Maximum power consumpon 992 W at 100% trac load, with IMIX packet size of 1000 bytes (48x1.5W SFP
+ opcs and 8x5W QSFP28 opcs)
DC Power Supply Module LEDs on ACX7348 Routers
The DC power supply module (PSM) on an ACX7348 router uses a single LED to indicate power status.
Figure 14 on page 29 shows the DC PSM components along with the status LED.
