Juniper SRX3600 Hardware Guide

Table 6: Switch Fabric Board LED Indicators (continued)
Indicated BehaviorStatusColorLabel
High availability is operating normally. All cluster members and
all HA links are available.
On steadilyGreenHA
An alarm is present on the HA link. All cluster members are
present, but some HA links are down. There are still enough
links for full functionality, but performance could be impaired
(reduced bandwidth could cause packets to get dropped, or
reduced resiliency as a single point of failure might now exist).
On steadilyAmber
A critical alarm is present on the HA. One or more cluster
members are missing or unreachable; or active when
secondary-path is engaged.
On steadilyRed
HA is disabled—Services gateway is not configured for clustering
or HA is disabled by secondary path.
OffDark (unlit)
CFM Status (pair)
The SFB and all installed CFM cards are operating normally.
The SERVICE LEDs on all installed CFM cards are green.
On steadilyGreenSERVICE
(top)
The SFB or one or more of the installed CFM cards has reported
a minor error condition. The SERVICE LEDs on the CFM cards
reporting the error are amber.
On steadilyAmber
The SFB or one or more of the installed CFM cards has failed.
The SERVICE LEDs on the failed CFM cards are red.
On steadilyRed
One or more of the installed CFM cards are disabled. The
SERVICE LEDs on the disabled CFM cards are dark.
OffDark (unlit)
The SFB and all installed CFM cards are operating normally.
The OK/FAIL LEDs on all installed CFM cards are green.
On steadilyGreenOK/FAIL
(bottom)
The SFB or one or more of the installed CFM cards has failed.
The OK/FAIL LEDs on the failed CFM cards are red.
On steadilyRed
One or more of the installed CFM cards are offline. The
OK/FAIL LEDs on the offline CFM cards are dark.
OffDark (unlit)
Routing Engine Status (pair)
