Table 6: Switch Fabric Board LED Indicators (continued)
Indicated BehaviorStatusColorLabel
The Routing Engine in RE0 is functioning as the master Routing
Engine. Only one Routing Engine can be installed.
On steadilyGreenRE0 (top)
The Routing Engine in slot RE0 is initializing.Blinking
Either the Routing Engine or Control Board function on RE0
has failed and is not operating normally.
On steadilyRed
The RE0 slot is empty.OffDark (unlit)
Unused.RE1
(bottom)
Power and Fan (pair)
The services gateway is receiving power. The Power Good
signal for all installed power supplies has been received after
Routing Engine initialization.
On steadilyGreenPWR (top)
The services gateway is in one of two states:
•
Services gateway is receiving power and is in the process of
booting up but has not yet initialized the Routing Engine.
•
Services gateway is in the process of graceful shutdown.
Blinking
One of the power supplies has failed, but the power available
from the remaining power supplies is sufficient to power all the
installed components.
On steadilyAmber
One or more of the power supplies have failed, and the power
available from the remaining power supplies is not sufficient to
power all the installed components.
On steadilyRed
The services gateway is shut down.OffDark (unlit)
The cooling system is operating normally.On steadilyGreenFAN
(bottom)
The cooling system has failed (one or more fans in the fan tray
are not operating normally).
On steadilyRed
