SRX380 Chassis
IN THIS SECTION
SRX380 Chassis Overview | 17
SRX380 Front Panel | 17
SRX380 Back Panel | 21
SRX380 Interface Modules Overview | 22
The SRX380 Services Gateway chassis is a rigid sheet metal structure that houses all of the other
components.
SRX380 Chassis Overview
The SRX380 chassis installs in standard 800–mm (or larger) enclosed cabinets, 19-in. equipment racks, or
telecommunications open-frame racks.
CAUTION: Before removing or installing components of a functioning services gateway,
attach an electrostatic discharge (ESD) strap to an ESD point and place the other end
of the strap around your bare wrist. Failure to use an ESD strap could result in damage
to the device.
The services gateway must be connected to earth ground during normal operation. The protective earthing
terminal on the side of the chassis is provided to connect the services gateway to ground.
SRX380 Front Panel
Figure 2 on page 18 shows the front panel of the SRX380. Table 3 on page 18 provides details about the
front panel components.
