CAUTION: To comply with intrabuilding lightning or surge requirements, the
intrabuilding wiring must be shielded. The shielding for the wiring must be grounded
at both ends.
To reduce the risk of fire, use 26 AWG telecommunication line wire.
SRX380 Services Gateway Physical Specifications
Table 14 on page 33 lists the physical specifications for the SRX380.
Table 14: Physical Specifications for the SRX380 Services Gateway
ValuePhysical Specification of Chassis
With handles—20.47 in. (52 cm)
Without handles—18.7 in. (47.5 cm)
Depth
17.36 in. (44.09 cm)Width
1.72 in. (4.37 cm)Height
15 lb (6.80 kg)Weight (with single power supply unit)
SRX380 Services Gateway Clearance Requirements for Airflow and
Hardware Maintenance
When planning the installation site for the SRX380 Services Gateway, you must allow sufficient clearance
around the device. Consider the following requirements:
•
For the operating temperature of the services gateway to be optimal, the airflow around the chassis
must be unrestricted. The three fixed fans provide front-to-back chassis cooling.
•
For service personnel to remove and install hardware components, there must be adequate space at the
front and back of the device. Allow at least 24 in. (61 cm) both in front of and behind the device.
•
If you are mounting the device in a rack with other equipment, ensure that the exhaust from other
equipment does not blow into the intake vents of the chassis.
33
