6. Secure the grounding cable lug to the grounding point with the washers and screws.
7. Dress the grounding cable and verify that it does not touch or block access to the services gateway
components and that it does not drape where people could trip on it. Ensure that the cable does not
obstruct the air flow of the fans.
NOTE: The device should be permanently connected to ground during operation.
Connecting the SRX380 Services Gateway to an AC Power Supply
Ensure that you have the following parts and tools available:
•
A power cord appropriate for your geographical location
•
A power cord retainer clip (provided with the device)
To connect AC power to the device:
1. Push the end of the power cord retainer strip into the slot above the power cord inlet until the strip
snaps into place. Ensure that the loop in the retainer strip faces the power cord (see
Figure 14 on page 45).
The power cord retainer clip extends out of the chassis by 3 in. (7.62 cm).
2. Press the small tab on the retainer strip to loosen the loop. Slide the loop until there is enough space
to insert the power cord coupler into the power cord inlet.
3. Locate the power cord or cords shipped with the device; the cords have plugs appropriate for your
geographical location. See Table 10 on page 26.
WARNING: Ensure that the power cord does not drape where people can trip on
it or block access to device components.
4. Insert the power cord coupler firmly into the power cord inlet (see Figure 14 on page 45).
5. Slide the loop toward the power supply until it is snug against the base of the coupler.
44
