Product Description Technical Manual
12 04045376 - 05/2016 Kaba access manager 92 30
3 Product Description
3.1 Overview
The Kaba access manager 92 30 is designed specifically for control of an individual
door (access/exit). The access manager can also be used for the decentralized access
control applications.
This is why the device is installed in secure indoor locations near the access. The de-
vice is designed for direct mounting on the wall. However, it can also be mounted in
suspended ceilings, wall recesses etc.
Depending on the device version, the access manager supports the connection of
registration units, readers/subterminals via RS-485 or Wiegand. The registration unit
allows contact-free reading and writing of RFID media in MIFARE or LEGIC technol-
ogy (depending on the configuration).
A 10BASE-T/100BASE-TX Ethernet interface is provided for communication with the
host on the network.
Power is supplied over PoE (Power over Ethernet). As an alternative the power supply
can also be performed via an external 24 V DC power supply unit.
The device has 4 inputs and 3 outputs. They can be used for control and monitoring
of Door management.
