Installation Technical Manual
36 04045376 - 05/2016 Kaba access manager 92 30
5 Installation
5.1 Installation conditions
5.1.1 General
An accurate installation of all components is a basic requirement for a properly func-
tioning device. The following installation instructions must be adhered to.
5.1.2 Installation site
The access manager is installed near the access. The device is designed for the direct
mounting on the wall. Depending on the conditions, the device can also be mounted
in suspended ceilings, wall recesses etc.
The access manager should be installed in the interior of the area to be secured.
The access manager must be installed exclusively in interiors.
Electromagnetic fields
The device must not be installed in the area of strong electromagnetic fields caused
by switching power supply, power lines, phase controllers, etc.!
5.1.3 Connections
The following connectors must have been prepared at the installation site of the ac-
cess manager:
• Ethernet network connection for host communication
For PoE power supply of the access manager, a PSE (Power Sourcing Equipment)
must be provided on the network cable for power feeding.
Possible methods for feeding the power supply via the PSE:
– End span (direct supply, e.g. via PoE switch)
– Midspan (supply via intermediate sources, e.g. PoE injector)
• 24 V DC power supply for the access manager (only for external 24 V DC power
supply as an alternative to the PoE power supply)
• Signal lines to door openers and contacts
• Coaxial lines to the registration units and/or data lines to the readers.
The installation lines have to be flush with the surface or be laid in the vandal-proof
area.
