Product Description Technical Manual
16 04045376 - 05/2016 Kaba access manager 92 30
3.3.5 Registration units
Two registration units can be connected to the access manager via coaxial cables
(connections Ant. A and Ant. B).
Supported registration units
• Kaba registration unit 90 00
• Kaba registration unit 90 01
• Kaba registration unit 90 02 (with PIN keypad)
• Kaba registration unit 90 03
• Kaba registration unit 90 04
Functional features
• A registration unit allows contact-free reading and writing of RFID media in MI-
FARE or LEGIC technology (depending on the configuration).
• The registration units can be used for CardLink validation and CardLink update.
• The registration units are supplied with power by the access manager.
Program number
A registration unit is reported to the communication software as a subterminal with a
program number.
Registration unit Program number
Registration unit without PIN keypad
801-00-X-K00
Registration unit with PIN keypad
802-00-X-K00
Addressing
By default, the addresses 1 and 2 are preset for the registration units and are not
available as subterminal addresses.
GID/DID Subterminal
00/01 Registration unit connection Ant. A
00/02 Registration unit connection Ant. B
From 00/03 Subterminals connected via the RS-485 subpartyline
This presetting can be changed using the parameters.
Parameterizing information
For the two registration units, it is not possible to use different reader configurations.
The reader configuration can be established via address 1 or address 2 and is valid for
both registration units.
External inputs, relays and vandal contact are not available.
