Kaba access manager 92 30 User Manual

Technical Manual Product Description
1304045376 - 05/2016Kaba access manager 92 30
3.2 Device variants
The Kaba access manager 92 30 is available in two device variants: The difference is in
the possible reader connection.
One variant allows connection of 2 RFID registration units or readers/subterminals via
RS-485. The other variant allows connection of 2 readers via Wiegand.
Equipment depending on the device version - Overview
Equipment / Variant RFID Wiegand
Communication
Ethernet interface X X
Connections for readers
Registration units X
Readers/subterminals via RS-485 X
Readers via Wiegand X
Serial interface
RS-232 for specific applications X X
Inputs / Outputs
4 digital inputs X X
3 relay outputs X X
Vandal contact Cover X X
Vandal contact Wall X X
Power supply
PoE (Power over Ethernet) X X
24 V DC power supply X X
Output voltages
5 V DC X
12 V DC X X
24 V DC (only for 24 V DC power supply) X X
Depending on the device variants, the corresponding terminals are available or not
available for readers.
