Installation Technical Manual
44 04045376 - 05/2016 Kaba access manager 92 30
5.6 Setting the PoE switches
Depending on the power supply type, the PoE switch must be set as described be-
low.
Power supply Standard/Power Switch position
PoE IEEE 802.3af (12.95 W) PoE
PoE+ IEEE802.3at (25.5 W) PoE+
External 24 V DC power
supply unit
12-60 W PoE+
In case of power supply via an external power supply unit, the switch position PoE+ is
required to prevent the access manager from limiting the power for external con-
sumers.
