14
2. Install the Strike
a. Align the paper template on the door frame at the desired handle
height, and along the vertical center line of the mortise (CL), which is
also the center line of the door edge, allowing for any bumpers on the
door frame.
Note: Respect applicable building codes regarding handle height.
b. Mark the locations of the dust box cutout and mounting screws for the
strike.
c. Mortise the door frame to receive the dust box, and drill the pilot holes
for the mounting screws (dimensions and depths marked on template).
d. Position the strike against the doorframe and align it with the
mounting screw holes. Trace the outline of the strike.
(CL)
