2. LOCK WITH 2 DIFFERENT SPACERS
The cylindrical unit and plate assembly is
shipped assembled in factory for 1
3
⁄4"
(44 mm) door thickness up to 1
13
⁄16" [46
mm] with 2 spacers "07"; 1 spacer "08"
and 2 flat head screws
5
⁄8" (16 mm) long.
For other door thicknesses, use Door
Thickness Table 2 for appropriate spacers
and screws included in the hardware bag.
Door Thickness Table 2
Door Spacer Spacer Screw
Thickness 07 08 length
1
3
⁄8" (35 mm) to 1
9
⁄16" (40 mm) 2 -
3
⁄8" (10 mm)
1
5
⁄8" (41 mm) to 1
11
⁄16" (43 mm) 1 1
1
⁄2" (13 mm)
1
3
⁄4" (44 mm) to 1
13
⁄16" (46 mm) 2 1
5
⁄8" (16 mm)
1
7
⁄8" (48 mm) to 1
15
⁄16" (49 mm) - 2
5
⁄8" (16 mm)
2" (51 mm) to 2
1
⁄16" (52.5 mm) 1 2
3
⁄4" (19 mm)
2
1
⁄8" (54 mm) to 2
3
⁄16" (56 mm) 2 2
3
⁄4" (19 mm)
2
1
⁄4" (57 mm) to 2
5
⁄16" (59 mm) - 3
7
⁄8" (22 mm)
2
3
⁄8" (60 mm) to 2
1
⁄2" (64 mm) 1 3
7
⁄8" (22 mm)
7
Screw Length Full Scale
Length
3
⁄8" (10 mm)
Length
1
⁄2" (13 mm)
Length
5
⁄8" (16 mm)
Length
3
⁄4" (19 mm)
Length
7
⁄8" (22 mm)
Correct Position of Spacers
See Table 2
