A-3. DOOR THICKNESS
Depending on the kind of spacers shipped with the lock, choose Table 1 or
Table 2 to prepare the attachment plate and cylindrical drive unit for door
thickness different than 1
3
⁄4" assembled in the factory.
Note: It is very important to assemble the spacers in the position shown.
1. LOCK WITH 3 DIFFERENT SPACERS
The cylindrical unit and plate assembly is
shipped assembled in factory for 1
3
⁄4"
(44 mm) door thickness (1
11
⁄16" [43 mm]
to less than 1
7
⁄8" [48 mm]) with 2 spac-
ers "04"; 1 spacer "02" and 2 flat head
screws
5
⁄8" (16 mm) LG. For other door
thicknesses, use Door Thickness Table 1
for appropriate spacers and screws
included in the hardware bag.
Prepare attachment plate and
cylindrical drive unit for door
thicknesses less than 1
11
⁄16"
(43 mm) or 1
7
⁄8" (48 mm) and
above according to the
Door Thickness Table 1
.
Door Thickness Table 1
Door Spacer Spacer Spacer Screw
Thickness 02 04 05 length
1
3
⁄8" (35 mm) to - 1 -
3
⁄8"
1
9
⁄16" (40 mm) (10 mm)
Over 1
9
⁄16" (40 mm) to - 2 -
1
⁄2"
less than 1
11
⁄16" (43 mm) (13 mm)
1
3
⁄4" (44 mm) DOOR 1 2 -
5
⁄8"
1
11
⁄16 (43 mm) to less than 1
7
⁄8" (16 mm)
1
7
⁄8" (48 mm) to 1 - 1
5
⁄8"
1
15
⁄16" (49 mm) (16 mm)
Over 1
15
⁄16" (49 mm) to 2 - 1
3
⁄4"
less than 2
1
⁄8" (54 mm) (19 mm)
2
1
⁄8" (54 mm) to - 1 1
3
⁄4"
2
3
⁄16" (56 mm) (19 mm)
Over 2
3
⁄16" (56 mm) to 2 1 1
7
⁄8"
2
3
⁄8" (60 mm) (22 mm)
Over 2
3
⁄8" (60 mm) to - - 2
7
⁄8"
2
1
⁄2" (64 mm) (22 mm)
6
Screws
Cylindrical
Unit
Assembly
05
04
02
Spacers
Attachment
Plate
Correct Position of Spacers
See Table 1
